NSF-Certified Idler Roller

Food Grade, Washdown

Designed for applications where sanitation matters, our NSF-certified washdown idler rollers support hygienic conveyor systems in food and other washdown-sensitive environments.

Engineered to meet NSF certification requirements, it is designed with cleanability in mind. From smooth external surfaces to its sealed construction, every element is intended to support effective washdown procedures and reduce the risk of contamination within the conveyor system.

Used alongside our NSF-certified motorized drive rollers, or in non-driven zones, these idler rollers allow OEMs and system integrators to maintain a consistent approach to hygienic conveyor design. They support the same sanitation expectations across the entire conveyor, not just the driven sections.

By incorporating NSF-certified components throughout the conveyor, system designers can reduce risk, simplify compliance efforts, and ensure alignment with food-grade and sanitary requirements.

The NSF-certified washdown idler roller complements our broader product offering, enabling complete conveyor systems that are both efficient and aligned with the demands of hygienic applications.
Ordering Information
  • NSF-Certified Design
  • Meets food-grade sanitation requirements
  • Sealed Roller Construction
  • Supports washdown without disassembly
  • Smooth External Surfaces
  • Enables faster, easier cleaning
  • Hygienic Roller Design
  • Reduces contamination risk in conveyor systems
  • Nitrile Seals
  • Excellent life expectancy
  • Clean Pinless Construction
  • Eliminates areas where debris can collect
  • Washdown-Ready Construction
  • Improves durability in washdown environments
  • Compatible with MDR Systems
  • Supports consistent sanitary conveyor design

General Technical Data

  • Available Tube Diameters: 48.6 mm (1.9”), 50 mm (1.97”)
  • Tube Material: SUS304 Stainless Steel
  • Bearing and Shaft Materials: SUS303 Stainless Steel
  • Minimum Length: 200 mm
  • Maximum Length: 800 mm
  • Certifications: CE, UKCA, RoHS, REACH, NSF

Senergy / Senergy-Ai
IP66/IP69K
Washdown Models

  • Same motor & gearbox construction as standard Senergy / Senergy-Ai but in a stainless steel package
  • Nitrile seals as standard - option for Viton seals available
  • Available in NSF certified package up to 800 mm length
Specifications:

Roller Drawings

Drawings are for both Senergy (JST) and Senergy-Ai (M8).  CAD drawings are formatted ANSI B size and pdf drawings are formatted ANSI A size

PR-AD-48-xxx-xxZxGQ
Senergy Roller, 1.9", Dual Groove, Non Threaded Hex Shaft, Spring Loaded End Shaft.


PR-AD-48-xxx-xxZxAQ
Senergy Roller, 1.9", Plain Straight - No Interlocking, Non Threaded Hex Shaft, Spring Loaded End Shaft.
