Pallet Handling Motor Drive Roller
Building the perfect pallet conveyor just got easier...not to mention smarter, faster, safer, and more cost-efficient. The 24VDC powered pallet handling motor rollers can move pallets up to 70” wide and effortlessly drive loads up to 2700 lbs.
Using our unique and industry-preferred ConveyLinx control card, PULSEROLLER pallet rollers can reach speeds up to 25 meters/minute with up to 49.3 N-m (436 in-lb) of torque. This enables you to move the heavier loads with less energy (current) while maintaining the required rates you expect.
With your choice of EthernetIP, Modbus TCP, ProfiNet, or EtherCat connectivity, the networked ConveyLinx cards facilitate just about any control strategy at a very attractive price. ZPA, transportation, indexing loads, minimum pressure...whatever the strategy, ConveyLinx can meet the challenge. You can monitor your full system over a single Ethernet network.
Our pallet handling motor rollers are available in standard 2.25", 2 3/8", and 2.5" diameters, You can choose from attachments including a sprocket, keyway, timing pulley, and much more.
- Safe and efficient 24VDC power
- Reliable gearbox design that's heat-treated and reinforced steel
- Highly efficient, powerful motor improves life expectancy
- Moves up to 2700 lbs
- 9-pin JST connector for simple and cost-effective Installation
- Senergy engine inside!
- Compact design
- Dual geared pallet - double the torque
- 2.25, 2 3/8 and 2.5"
Card title
Card subtitle
Some quick example text to build on the card title and make up the bulk of the card's content.
Card linkAnother link- Reduces Cost and Saves Time
- Super Compact Design
Drawings
-
63-5 Dia Dual Sprocket
Part Number: PR-PD-63-XXX-XXASDQ
Description: PulseRoller 63.5 Dia, Dual Sprocket, drawing in DWG format. -
63-5 Dia Dual Sprocket
Part Number: PR-PD-63-XXX-XXASDQ
Description: PulseRoller 63.5 Dia, Dual Sprocket, drawing in PDF format. -
63-5 Dia Plain Straight
Part Number: PR-PD-63-XXX-XXASAQ
Description: PulseRoller 63.5 Dia, Plain Straight, drawing in DWG format. -
63-5 Dia Plain Straight
Part Number: PR-PD-63-XXX-XXASAQ
Description: PulseRoller 63.5 Dia, Plain Straight, drawing in PDF format. -
PR-PD-63-xxx-xxASAQ
Part Number: PR-PD-63-xxx-xxASAQ
Description: Senergy Pallet Roller, 63.5mm, JST, Plain Straight, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in DWG format. -
PR-PD-63-xxx-xxASAQ
Part Number: PR-PD-63-xxx-xxASAQ
Description: Senergy Pallet Roller, 63.5mm, JST, Plain Straight, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in PDF format. -
PR-PD-63-xxx-xxASAQ
Part Number: PR-PD-63-xxx-xxASAQ
Description: Senergy Pallet Roller, 63.5mm, JST, Plain Straight, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in STEP format. -
PR-PD-63-xxx-xxASHQ
Part Number: PR-PD-63-xxx-xxASHQ
Revision: A (24-June-2022)
Description: Senergy Pallet Roller, 63.5mm, JST, Micro-V, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in DWG format. -
PR-PD-63-xxx-xxASHQ
Part Number: PR-PD-63-xxx-xxASHQ
Revision: A (24-June-2022)
Description: Senergy Pallet Roller, 63.5mm, JST, Micro-V, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in PDF format. -
PR-PD-63-xxx-xxASHQ
Part Number: PR-PD-63-xxx-xxASHQ
Description: Senergy Pallet Roller, 63.5mm, JST, Micro-V, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in STEP format. -
PR-PD-63-xxx-xxYSDY
Part Number: PR-PD-63-xxx-xxYSDY
Description: Senergy Pallet Roller, 63.5mm, JST, Dual Sprocket #40-21T, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in DWG format. -
PR-PD-63-xxx-xxYSDY
Part Number: PR-PD-63-xxx-xxYSDY
Description: Senergy Pallet Roller, 63.5mm, JST, Dual Sprocket #40-21T, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in PDF format. -
PR-PD-63-xxx-xxYSDY
Part Number: PR-PD-63-xxx-xxYSDY
Description: Senergy Pallet Roller, 63.5mm, JST, Dual Sprocket #40-21T, Threaded Hex Shaft, Spring Loaded End Shaft. Drawing in STEP format.
-
Specifications
-
Characteristics
Description: This document will provide you with the speed codes and torque perfromance data for the Senergy Pallet Motor Roller. -
General Information
Description: This document will provide you with all general information for the Pallet Roller's such as Technical Data, Wall Thickness, Static Load Capacity, Avalaible minimum lengths, Dimensions, and Characteristics data. -
Installation Caution
Description: This document provides installation notes for tightening torque for the Senergy Pallet Motor Roller. -
Part Number Definition
Description: This document will give you the necessary information to allow you to build your own PulseRoller Pallet Motor Roller part number for ordering. -
RoHS Declaration of Conformity
Specification: Directive 2015/863/EU (RoHS 3)
Description: Declaration of Conformity for RoHS 3 for all Senergy and Senergy-Ai motor units. -
Selecting Power Supply
Description: This document will help you in selecting the right power supply for your project using PulseRoller's.
-
Compatible Controls
Compatible Controls
