ConveySense - Economical Sensing Solution

ConveySense are economical zone presence sensors for your accumulation conveyor.

There is no need to pay more for sensor features that are not required on zero pressure conveyor. Featuring a sensing distance of nearly 5'-0", an NPN signal alert when parts are present, and an RJ12 connection at the end for quick connections to the controls architectures, you can rely on ConveySense. Select the cable length of your choice, and choose diffuse or retro-reflective.

That's it!

Faster commissioning times
Economical
Specifically for use with our controllers
Options

Card title

Card subtitle

Some quick example text to build on the card title and make up the bulk of the card's content.

Card link Another link

Reduces Cost and Saves Time
Super Compact Design

Deterministic Network

Collects Important Information

Robust M8 Connections

CE ETL UL and IP54

Drawings

Retro-Reflective Sensor Kit
Diffuse Sensor
- Diffuse_Sensor
  Part Number: IN-RT-P2527S14
  Description: Drawings and Documentation for the Sick Diffuse Photo-Eye with RJ12 Connector. Bracket is not included.
- Diffuse_Sensor_Bracket
  Part Number: IN-BEF-WK-WTR
  Description: Drawings and Documentation for Sick Optic Diffuse Sensor Bracket.
M12 to RJ-11 Adapter
- M12_RJ11_Converter
  Part Number: IN-M12-RJ11-EXT-100
  Description: M-12 to RJ11 Converter Extension Cable drawing in DWG format. This cable typically is used to connect M12 Diffuse Sensor to ConveyLinx or IQZonz Modules.
- M12_RJ11_Converter
  Part Number: IN-M12-RJ11-EXT-100
  Description: M-12 to RJ11 Converter Extension Cable drawing in PDF format. This cable typically is used to connect M12 Diffuse Sensor to ConveyLinx or IQZonz Modules.

Economical and Simple to Install

There is no need to pay more for Sensor features that are not required on Zero Pressure Conveyor. Select the cable length of your choice, and choose Diffuse or Retro-Reflective.

-CE certified, RoHS compliant, IP54 raitng
-ETL Certified to UL Standards (Optional)
-Tube material:	Mild stell, zinc plating/ Stainless steel (SUS304)
-Roller diameter:	48.6 mm (1.9"), 50.0 mm (1.97")
	57.0 mm (2.24"), 60.5 mm (2.38")
-Min. roller length:	Refer to the "Availale minimum roller length table" below
-Max. roller length:	1000 mm *Contact us for longer than 1000 mm.
-Cable length:	600 mm (SENERGY) / 1000 mm (SENERGY-Ai) *Contact us for extension cables
-Motor Connector:	JST (SENERGY) /M8-4pin (SENERGY-Ai)
-Operation:	0.5 sec ON / 0.5 sec OFF duty cycle (Minimum) or continuous within rated load

Technical data

	ECO mode	BOOST mode	BOOST-8 mode
Voltage	DC24V
Nominal Output	40W	50W	50W
Rated current	2.5A	3.5A	3.5A
Starting current	3.0A	5.0A	8.0A
Ambient temperature	14 ~ 140°F
Ambient humidity	10 ~ 90% RH (No condensation)

Characteristics data

*Rated torque and rated tangential force of BOOST-8 are the same value as BOOST.
Speed code	Gear box	Gear ratio	ECO mode							BOOST & BOOST-8 mode
			Speed (f/min)	Torque (in-lbf)		Tangential force (lbf)		Current (A)		Speed (f/min)	Torque (in-lbf)			Tangential force (lbf)			Current (A)
			Speed (f/min)	Rated	Starting	Rated	Starting	Rated (max)	Starting	Speed (f/min)	Rated	BOOST Starting	BOOST-8 Starting	Rated	BOOST Starting	BOOST-8 Starting	Rated (max)	BOOST Starting	BOOST-8 Starting
15	3 stage	45.00	6.4 ~ 64.7	26.2	145.0	27.4	151.6	2.5	3.0	6.4 ~ 46.8	47.4	189.1	215.0	49.9	197.7	224.8	3.5	5.0	8.0
20		33.00	8.8 ~ 88.3	19.2	106.2	20.1	111.0			8.8 ~ 63.9	34.9	138.4	157.4	36.5	144.7	164.5
25		27.00	10.7 ~ 107.8	15.7	87.0	16.4	90.9			10.7 ~ 77.9	28.6	113.5	129.0	29.9	118.6	134.8
35	2 stage	18.33	15.8 ~ 159.0	10.6	59.0	11.1	61.6			15.8 ~ 115.0	19.4	76.9	87.4	20.3	80.4	91.4
45		15.00	19.2 ~ 194.0	8.7	48.3	9.1	50.5			19.2 ~ 140.3	15.9	63.0	71.6	16.6	65.9	74.9
60		11.00	26.3 ~ 285.0	6.4	35.4	6.7	37.0			28.3 ~ 191.6	11.6	46.1	52.4	12.1	48.2	54.8
75		9.00	32.1 ~ 323.2	5.2	29.0	5.4	30.3			32.1 ~ 233.8	9.5	37.8	43.0	9.9	39.5	44.9
95	1 stage	6.8182	42.3 ~ 426.7	3.9	21.9	4.1	22.9			42.3 ~ 308.6	7.2	28.6	32.5	7.5	29.9	34.0
125		5.00	57.7 ~ 581.9	2.9	16.1	3.0	16.8			57.7 ~ 420.8	5.3	21.0	23.8	5.5	21.9	24.9
175		3.6667	78.8 ~ 794.9	2.1	11.8	2.2	12.3			78.8 ~ 574.8	3.8	15.3	17.4	4.0	16.0	18.2
215		3.00	96.2 ~ 969.8	1.7	9.6	1.8	10.1			96.2 ~ 701.3	3.1	12.6	14.3	3.3	13.1	14.9

Robust and Unique Gearbox Design significantly improves life expectancy
Provides wide ranges of Speed and Power using Low Energy
JST Cabling for Simple Installation and Robust Cable Routing, IP54
CE Approved
ROHS Compliant
ETL Certified to UL Standards Available
IP54 & IP66 Ratings Available
ETL Certified to UL Standards Available
High Torque Rollers Available
Freezer and Wash-Down Rated Rollers Available
Mechanical Braking Available

Use our contact page to be directed to the correct sales channel.

Need help? Contact our product specialists TODAY!
