SENERGY-Ai Motor Roller

Senergy-Ai motor drive rollers are powerful, efficient, and versatile solutions suitable for virtually any unit handling conveying application. Senergy-Ai MDRs can reach speeds up to 1000 fpm, with a starting torque up to 215 in/lbs.

Senergy-Ai motorized drive rollers feature a combination of speed and power allowing them to be used in lower speed, heavy-duty applications such as pallet handling, as well as for high-speed carton or tote handling.

Senergy MDRs operate at a low 40 dba, quieter than a typical conversation. They utilize a safe and effective 24VDC power supply and consume up to 70% less energy than alternatives.

Senergy's power and efficiency are derived from a unique planetary gearbox design and a powerful brushless DC motor. Senergy features only 11 gearbox combinations. This makes ordering and stocking MDRs much more manageable.

Senergy's range and performance characteristics are suitable for speeds between 6 to 1000 fpm and starting torque up to an amazing 215 in/lbs.

Regardless of the project, type of conveyor, the weight or speed of the load you really only need one type of roller. Senergy!

Senergy-Ai uses a reliable and proven M8 connector which is then connected to an external Ai equipped controller of your choice. The hall-effect signals are digitally coded inside the motor by a micro-controller, which makes it possible to communicate precise rotor position through only one pin in the M8 connector to the external Ai controller. The micro-controller also digitally encodes motor data such as part number, serial number, gear reduction, motor temperature and run time, etc. The external control uses all this data for multiple functions such as positioning control, fault detection and alarms, and to provide data for preventive/predictive maintenance.

Robust and unique gearbox design significantly improves life expectancy
Provides wide ranges of speed and power using low energy
M8 connectors for quick & simple Installation
IP54 & IP66 ratings available
High torque with up to 50 watts of power
Freezer and washdown rated rollers available
NSF Rated Washdown rollers available

Card title

Card subtitle

Some quick example text to build on the card title and make up the bulk of the card's content.

Card link Another link

Reduces Cost and Saves Time
Super Compact Design

Deterministic Network

Collects Important Information

Robust M8 Connections

CE ETL UL and IP54

Roller Drawings

Bracket Drawings

Specifications

Accessories

Compatible Controls

- ConveyLinx-Ai Family
- E-Qube-Ai
- MotionLinx-Ai

Modular & Simple Install

A conveyor section powered by a single Pulseroller Senergy motor drive roller (MDR) is mechanically linked with just enough free-turning (gravity type) rollers to constitute a controllable zone. This zone is usually not much longer than the item to be conveyed. With the proper control system strategy, an end-user can easily assemble individual MDR zones like building blocks to make zero pressure accumulation conveyor subsystems. Instead of having a single 100-ft. accumulation conveyor with its 5HP, 480-volt gear motor, and its own air feed drop; you now have 10 manageable 10-ft. modular accumulation sections that connect together. You don't have to supply air piping, and your power sourcing can be as simple as plugging into a standard 120-volt household wall receptacle.

Saves Energy

One of the greatest advantages of motorized drive roller conveyors is the fact that, with the proper control system strategy, MDR zones run just 10-50% of your operational time. Contrast this with conventional conveyors which typically run all the time whether they are accumulating product or not. This means you will enjoy significant energy savings with a Senergy MDR. Customers are seeing energy savings from 30 to 70%.

Safer

Our Senergy motorized drive roller is powered by 24 volts DC, and has no major pinch points. It provides just enough motive power and torque to control a short zone, and there is never enough drive power to be considered dangerous. In most cases, you can literally grab a running motorized roller with your bare hand and make it stop with only a handshake grip.

Quiet

Conveyor systems powered by Senergy MDRs are much quieter than conventional conveyors. They operate only when necessary and at a quiet 40dB.

Truly Plug and Play

The phrase "plug and play" has become ubiquitous in product marketing. Many companies and products promise you plug and play for obvious reasons, but in truth they fail to deliver the plug or the play. When you use Senergy and ConveyLinx together in your motorized drive roller conveyor systems, plug and play becomes a reality.

Senergy-Ai motor rollers are installed with simple plug in M8 connectors. With our patented installation process, the "play" in many cases is as easy as a mouse click in our EasyRoll software. Taking it a step further, when customizations are necessary, you simply plug in an Ethernet cable to connect ConveyLinx to your PC running EasyRoll. Simple as can be!

Reduced Maintenance Costs

It’s simple. Because our Senergy MDRs run only as needed, there's less wear and tear on components. We use sealed for life bearings, and most of our motors are interchangeable. This means you only have to stock one spare part.

Conformance:	CE, RoHS, IP54
Certifications:	ETL Listed to UL 1004-1 & UL 1004-6
Tube Material Options:	Zinc Plated Mild Steel, Stainless (SUS304)
Roller Diameter::	48.6 mm (1.9"), 50.0 mm (1.97")
	57.0 mm (2.24"), 60.5 mm (2.38")
Min. Roller Length:	Refer to the "Available minimum roller length" table
Max. Roller Length:	1000 mm
Cable Length:	1000 mm
Motor Connection:	4-Pin M8
Duty Cycle:	0.5 sec ON / 0.5 sec OFF minimum
Operation:	Continuous at rated load/current without overheating

Technical Data

	ECO Mode	BOOST Mode	BOOST-8 Mode
Voltage	DC24V
Nominal Output	40W	50W	50W
Rated current	2.5A	3.5A	3.5A
Starting current	3.0A	5.0A	8.0A
Ambient temperature	-10 ~ 40°C (14 ~ 104°F)
Ambient humidity	10 ~ 90% RH (No condensation)

Available Minimum Roller Length (mm)

Motor Type	Speed Code	Interlocking option

		Plain straight	Micro V-pulley	Round Groove Pulley	Round Groove
SENERGY 48.6 / 50.0	15, 20, 25	325	318	325	357
	35, 45, 60, 75	301	294	301	333
	95, 125, 175, 215	274	267	274	306
SENERGY-Ai 48.6 / 50.0	15, 20, 25	330	323	330	362
	35, 45, 60, 75	306	299	306	338
	95, 125, 175, 215	279	272	279	311

Senergy Ai Plain Straight w grey Border-01.png

Senergy Ai Dual Groove w grey Border-01.png

Senergy Ai Dual Groove Pulley w grey Border-01.png

Available Speed Codes with Performance Data

Speed Code	Gear Box	Reduction Ratio	ECO-Mode
			Speed (m/min)	Torque (N-m)		Tangential Force (N)		Current (A)
			Speed (m/min)	Rated	Starting	Rated	Starting	Rated (max)	Starting
15	3 stage	45	2.0 ~ 19.7	2.9	16.3	122.2	647.6	2.5	3.0
20		33	2.7 ~ 26.9	2.1	12.0	89.4	493.8
25		27	3.3 ~ 32.8	1.7	9.8	73.3	404.7
35	2 stage	18.3	4.8 ~ 48.5	1.2	6.6	49.7	274.3
45		15	5.9 ~ 59.1	0.9	5.4	40.7	224.8
60		11	8.0 ~ 80.8	0.7	4.0	29.8	164.6
75		9	9.8 ~ 98.5	0.5	3.2	24.4	134.9
95	1 stage	6.81	12.9 ~ 130.1	0.4	2.4	18.5	102.2
125		5	17.6 ~ 177.4	0.3	1.8	13.5	74.9
175		3.6	24.0 ~ 242.3	0.2	1.3	9.9	54.8
215		3	29.3 ~ 295.6	0.1	1.0	8.1	44.9

¹ Rated Torque and Tangential Force values are the same for BOOST and BOOST-8
Speed Code	Gear Box	Reduction Ratio	BOOST & BOOST-8 Mode¹ ²
			Speed (m/min)	Torque (N-m)			Tangential Force (N)			Current (A)
			Speed (m/min)	Rated	BOOST Starting	BOOST-8 Starting	Rated	BOOST Starting	BOOST-8 Starting	Rated (max)	BOOST Starting	BOOST-8 Starting
15	3 stage	45	2.0 ~ 14.3	5.4	21.3	24.3	222.2	879.6	1000.0	3.5	5.0	8.0
20		33	2.7 ~ 19.5	3.9	15.6	17.7	162.6	643.8	732.0
25		27	3.3 ~ 23.8	3.2	12.8	14.5	133.3	527.7	600.0
35	2 stage	18.3	4.8 ~ 35.0	2.1	8.6	9.8	90.3	357.7	406.6
45		15	5.9 ~ 42.8	1.8	7.1	8.1	74.0	293.2	333.3
60		11	8.1 ~ 58.4	1.3	5.2	5.9	54.2	214.6	244.0
75		9	9.8 ~ 71.3	1.0	4.2	4.8	44.4	175.9	200.0
95	1 stage	6.81	12.9 ~ 94.1	0.8	3.2	3.6	33.6	133.2	151.5
125		5	17.6 ~ 128.3	0.6	2.3	2.7	24.6	97.7	111.1
175		3.6	24.0 ~ 175.2	0.4	1.7	1.9	18.0	71.5	81.3
215		3	29.3 ~ 213.8	0.3	1.4	1.6	14.8	58.6	66.6

Ingress Protection: IP54 (IP66 for Wash Down Models)
